Plysolene

Oil and gas plant 1

Plysolene PIB is  a waterproofing membrane for pipework and ventilation ductwork.

Plysolene PIB is  a waterproofing membrane for pipework and ventilation ductwork. Plysolene PIB has outstanding properties over a wide temperature range (-30°C to 100°C) it is used globally in oil refineries, chemical works, Petrochemical plants and power stations.

Plysolene is used by many contractors due to its ease of use, demanding joints and difficult shapes are simply cut and welded on site.

Plysolene PIB is produced from high molecular weight poly­iso­butylene, modified to achieve optimum properties.

It will not harden, its virtually non-ageing,ozone resistant and UV resistant.

Thickness Finish Width Length Approx Roll Weight
0.8mm Chalked 1000mm 15 metres 19 Kgs
0.8mm Paper Interleaved 1000mm 15 metres 19 Kgs
0.5mm Chalked 1000mm 25 metres 23 Kgs
0.8mm White Chalked (For Internal Use Only) 1000mm 15 metres 19 Kgs
1.0mm Chalked 1000mm 15 metres 24 Kgs
1.0mm Paper Interleaved 1000mm 15 metres 24 Kgs
1.2mm Chalked 1000mm 12.5 metres 24 Kgs
1.2mm Paper Interleaved 1000mm 12.5 metres 24 Kgs

Plysolene PIB is generally unaffected by:

Hydrochloric Acid (dil & conc), Acetone, Sulphuric Acid (dil & conc), Acetic Acid, Aqueous Caustic Lime, Methanol and Ethanol, Aqueous Hydro­sul­phite, Formic Acid (dil & conc), Methyl Acetate, Copper Sulphate solutions, Sodium Chloride, Potassium Permanganate, Ethylene Glycol, Hydrogen Peroxide, Chromic Acid, Glycerine, Ethyl Acetate, Sulphonic Acid, Phenol, Chloros­ul­phuric Acid, Cyclohexone, Sodium Hydroxide (dil & conc), Ammonia, Naphthalene Sulphuric Acid, Solvents E13/E14.
